Architectural Compliance, Powered by Building Intelligence.

Upload architectural drawings, parse IFC/BIM models, and verify Dutch Building Regulations (BBL) in seconds. Detect setbacks, ceiling height breaches, and fire compartmentation issues before permit submission.

✓Deterministic BBL Engine
✓IFC 4x3 Spatial Parser
✓Wkb Cryptographic Trail
|1:100
Boundary Setback: 3.40m [PASS BBL Art. 2.14]Clearance: 2.15m < Req: 2.60mBBL Art. 4.23 (Ceiling Height Fail)H: 2.62m [PASS]
Amstelkwartier Kavel 4B[FAIL]
BBL Art. 4.23 (Hoogte verblijfsgebied)
Measured: 2,150 mm | Req: 2,600 mm
Entity: IfcSpace / Room_402_Living
Inspect statutory rule→
BUILT NATIVELY UPON EUROPEAN & DUTCH BUILDING STANDARDS
BBL 2024
Besluit bouwwerken leefomgeving

Dutch National Statutory Decree

NEN 2580
Oppervlakten & Inhouden

BVO, GO, VVO algorithmic splits

NEN 6068
Brandveiligheid & Rook

WBDBO & Subcompartimentering

IFC 4x3 & 2x3
buildingSMART OpenBIM

Native geometry & property sets

DSO API
Digitaal Stelsel Omgevingswet

Direct municipal intake channel

Wkb Borging
Kwaliteitsborging Bouwen

Immutable as-built quality dossiers

VERIFICATION WORKFLOW

Deterministic Compliance Architecture

From raw vector CAD and IFC schema models to legally defensible municipal permits.

01 / INGEST

Ingest CAD & BIM

Accepts 2D DWG, DXF, Vector PDF, and IFC 2x3/4x3. Auto-calibrates spatial reference systems (Rijksdriehoek RD New / EPSG:28992).

Formats: IFC, DWG, DXF, PDF
02 / PARSE

Spatial Extraction

Deconstructs slabs, boundary walls, door clear-openings, window lux vectors, and automated NEN 2580 BVO/GO surface polygons.

Geometric Engine: Open CASCADE
03 / SOLVE

Rule Engine

Evaluates geometry against 1,200+ codified BBL decrees: egress travel paths, ceiling clearances, ventilation debit, and fire wraps.

Rule Sets: BBL, NEN 6068, Bouwbesluit
04 / VERIFY

Evidence Tagging

Pinpoints millimeter-accurate deviations with coordinate stamps, cross-sectional cutaways, and legal requirement deltas.

Resolution: ±1.0 mm tolerance
05 / DOSSIER

Cryptographic Report

Compiles tamper-evident SHA-256 certified compliance dossiers formatted for municipal DSO intake and accredited Wkb assurers.

Output: ISO PDF/A-1b & JSON-LD
RULE SOLVER MATRIX

Codified Legal Logic with Millimeter Precision

Click any statutory rule in the evaluation stream to inspect its mathematical derivation.

Active Rule Evaluation StreamProject: Herengracht 412 Redevelopment
Rule IDStatutory RequirementMeasuredThresholdStatusEvidence Link
BBL-4.23Habitable Area Minimum Height2,620 mm≥ 2,600 mmPASSView 3D Mesh ↗
BBL-3.81Daylight Factor Equivalent Area0.42 m²≥ 0.50 m²FAILView Window_W04 ↗
BBL-2.102Escape Route Travel Distance28.4 m≤ 30.0 mPASSView Corridor_L1 ↗
NEN-2580Functional Space DesignationUnverifiedUser Input Req.NEEDS EVIDENCEUpload Spec ↗
NEN-6068Brandwerendheid Scheidingsconstructie60 min WBDBO≥ 60 minPASSView Wall_W12 ↗
Swipe horizontally to inspect table columns →
Rule InspectorBBL Art. 4.23
Legal Definition
“Een verblijfsgebied heeft een vrije hoogte van ten minste 2,6 m boven de vloer van dat gebied.”
Parameter Derivation
Z_floor_finish = +3.100 m
Z_ceiling_sub = +5.720 m
Clearance = 5.720 - 3.100 = 2,620 mm
Tolerance Delta:+20 mm (Compliant)
Spatial Anchor:RD X:124401 Y:489115
VERIFIED DETERMINISTIC PASS
OPEN STANDARDS

Native BIM Understanding Without Vendor Lock-in

Wabocheck parses raw building elements directly from open standard IFC files, preserving exact topology, property sets, and geometric relationships.

IFC Spatial Tree Parser v4.3.2
42.8 m² GO Solved
IfcSpace: Verblijfsruimte 101Oppervlakte: 42.80 m² GOClear Width: 930mm [PASS]
01 / IFC BOUNDARY RECONSTRUCTION

IfcSpace Boundary Calculation: 42.8 m² GO

Automatic deduction of load-bearing structural columns, shafts, and perimeter recesses strictly adhering to NEN 2580 norms.

02 / ACCESSIBILITY ENVELOPE

IfcDoor Minimum Clear Opening: 930 mm

Full accessibility compliance checks under BBL Art. 4.22. Evaluates door frame jamb rebates and threshold elevations.

03 / PROPERTY SET RESOLUTION

Automated LOD 200–400 Verification

Deep semantic inspection of standard and custom schema property sets including Pset_SpaceCommon, Pset_DoorCommon, and Qto_WallBaseQuantities.

CAD WORKBENCH

Interactive In-Browser Drawing Studio

Draft, inspect, and fix regulatory violations dynamically with zero CAD software installation.

Direct DXF/DWG ExportLive BBL Constraint Engine ActiveOpen Studio
Floorplan_Level_02.dwg
Real-time BBL Check: 0 Errors | 1 Warning [BBL 3.81]
4,500 mm3,200 mmLiving / Verblijfsruimte 01GO: 24.2 m² | Req. Height: 2,600 mm [PASS]Kitchen & DiningVentilation Debit: 21 dm³/s [PASS]Door: 930 x 2,315 mmWindow W02: 0.48 m² daylight [Warning: Threshold 0.50 m²]
Wall Assembly: 200 mm Brick Cavity
X: 3,420 Y: 1,850 mmOpen Live Studio ↗
MUNICIPAL DOSSIER

Audit-Ready Reports for Municipalities & Quality Assurers

Generate cryptographically verifiable statutory compliance dossiers formatted specifically for the Dutch Omgevingswet and Wkb quality assurers.

Statutory Compliance Validation Report

WABOCHECK STATUTORY COMPLIANCE REPORT — WKB DOSSIER

BAG-ID: 0363010012093841 | Project: Herengracht 412, Amsterdam | Datum: 24-02-2026
DSO VALIDATED
SHA-256 Digest:7f83b1657ff1fc53b92dc18148a1d65dfc2d4b1fa3d677284addd200126d9069[IMMUTABLE]
Executive Statutory Status: 94% Pass (47 of 50 Articles Validated)
● 94% PASS (47)● 4% NEEDS EVIDENCE (2)● 2% FAIL (1)
Itemized BBL Chapter 3 & 4 Verification Checklist
[✓ PASS]Art. 3.81 DaglichtoppervlakteVerblijfsruimte 1: 3.82 m² (vereist: ≥ 2.10 m²)
Δ +1.72 m²
[✓ PASS]Art. 4.22 Doorgang en Vrije BreedteDeur D01: 930 mm (vereist: ≥ 850 mm)
Δ +80 mm
[✓ PASS]Art. 4.23 Plafondhoogte VerblijfsgebiedGemeten: 2,640 mm (vereist: ≥ 2,600 mm)
Δ +40 mm
[⚠ REVIEW]Art. 2.102 Vluchtroute LengteGemeten: 29.2 m (max toelaatbaar: 30.0 m)
Margin: 0.8m
Signee: Ir. M. van der Linden (Kwaliteitsborger Wkb)
Certificaat: SKH-BOK-0914-NL | Timestamp: 2026-02-24T14:18:02+01:00
Statutory Conformance Sealed
SITE AUGMENTATION

Millimeter Spatial Overlay on the Construction Site

Superimpose BIM models directly onto physical job sites through tablet LIDAR and RTK GNSS. Inspect physical structural pours against statutory building code specifications before concrete sets.

Sub-centimeter RTK GNSS field anchoring (EPSG:28992).
Instant comparison of poured column centerlines vs. IFC geometry.
Direct field photo tagging to the immutable Wkb Quality Dossier.
Launch AR Field Inspector
RTK Fix: ±4mm Accuracy|
Battery 94% • 5G Low-Latency
Construction Site Interior for AR AlignmentTolerance Delta: +4mmWithin NEN-EN 13670 Class 1 (Permissible)
ENTERPRISE ASSURANCE

Engineered for Statutory Rigor and Data Sovereignty

Built specifically for leading European architecture practices, general contractors, and statutory review boards.

Role-Based Access (RBAC)

Granular permission matrices for Lead Architects, Structural Engineers, Wkb Independent Quality Assurers, and Municipal Building Inspectors.

SAML 2.0 / Okta SSOExplore →

Cryptographic Audit Trail

Every drawing commit, parameter modification, and compliance evaluation is immutably hashed and timestamped to provide undisputed legal auditability.

SHA-256 Merkle LedgerExplore →

Sovereign EU Isolation

Strict ISO 27001 and GDPR compliance with data hosted exclusively in Amsterdam/Frankfurt facilities. Zero client model training.

EU Data Residency

Direct DSO & Omgevingsloket API

Native bi-directional synchronization with the Dutch Digitaal Stelsel Omgevingswet (DSO) API standard for friction-free digital permit filing.

REST & Webhook ReadyExplore →
TRANSPARENT LICENSING

Platform Access Tiers

Deterministic building intelligence scaled for independent architects, engineering studios, and general contractors.

Starter

AEC TIER

Architects, Homeowners & Small Renovators

€0Free Tier
  • 1 Active Project Workspace
  • 1 Admin Seat
  • Basic CAD Viewer (2D DXF & PDF)
  • BBL Statutory Lite Search
  • Standard BVO/GO Area Calculation
  • Manual Photo & Plan Upload (100MB)
  • Statutory Summary PDF Export
Initialize Free Tier
RECOMMENDED FOR PRACTICES

Professional

AEC TIER

ZZP Architects, Engineers & Subcontractors

€70/ Month
  • 10 Active Project Workspaces
  • 5 Team Seats + Unlimited Viewers
  • Full IFC 4x3 & 2x3 Spatial Engine
  • Automated BBL & NEN 2580 Checks
  • In-Browser Drawing Studio with Live HUD
  • AR Field Inspection Tool with RTK GNSS
  • Wkb Quality Dossier Automation
  • Cryptographic SHA-256 PDF Reports
  • Priority Support (4-hour response SLA)
Start Professional Tier

Business / Enterprise

AEC TIER

General Contractors & Architectural Practices

€200/ Month
  • Unlimited Project Workspaces
  • 20+ Team Seats + Granular RBAC
  • Direct Digitaal Stelsel Omgevingswet (DSO) API
  • Continuous Automated BBL Rule Solver
  • Immutable Merkle Audit Log Trail
  • Multi-User Real-Time AR Site Sync
  • Sovereign EU Data Residency & SLA
  • Dedicated Engineering Account Lead
Deploy Enterprise
ENGINEERING REVIEWS READY IN < 60 SECONDS

Know What Complies Before You Build.

Eliminate permitting delays, prevent costly site re-work, and generate verifiable BBL compliance dossiers in minutes with the European AEC engine.

Start Your First Compliance Check
• Open standard IFC 2x3/4x3• Native DWG / DXF / Vector PDF• Direct DSO & Wkb Compatible• Instant Verification Evaluation
